SBC State Machine for Model-Based Systems Engineering: Toward a Unified View of the System

Systems Modeling Language (SysML) is a general modeling language for model-based systems engineering (MBSE) applications. The SysML specification defines a set of language concepts that is used to model the (static) structure and (dynamic) behavior of a system. The SysML concepts include (1) an abstract syntax that defines the language concepts and is described by a metamodel, and (2) a concrete syntax, or notation, that defines how the language concepts are represented and is described by a user model.Since SysML is a multi-diagram approach, there are always some inconsistencies between different diagrams in the user model. To ensure and check the consistency, a metamodel that defines the abstract syntax of a modeling language needs to provide a unified semantic framework for defining consistency rules to impose constraints on the structure (i.e., blocks) or behavior (i.e., activities) constructs. It is hoped that through this unified semantic framework, each diagram in the user model can be projected as a view of the metamodel.Unfortunately, most current SysML metamodels do not have the ability to project each diagrams in the user model as a view of the metamodel. In this book, we developed SBC State Machine (SSM) as a metamodel for SysML. In SBC State Machine, each diagram in the user model will be projected as a view of the metamodel. Therefore, we claim that SBC State Machine genuinely provides a unified semantic framework to ensure model consistency for SysML.

Author: Shuh-Ping Sun

Publisher: Independently Published

Publication Date: 44103

Number of Pages: 248 pages

Binding: Science

ISBN-10:

ISBN-13: 9798691750557
